Configuration
Audio-Transceiver-Fiber · 8
English
Adjusting a connection in the terminal emulation program
How to adjust the connection in the terminal emulation program:
1. Start any terminal emulation program (HyperTerminal or PuTTY, for example).
2. Create a new connection in the terminal emulation program and enter the fol-
lowing connection settings:
3. Connect the Service interface of the signal extender’s transmitter or receiver to one
of the computer’s USB interfaces. Use the supplied service cable for this purpose.
Operating the setup menu
The setup menu lists all signal extender settings in tabular form:
The current setting of the different functions is displayed in the right column. The
three dots in the right column indicate that this particular function provides a sub
dialogue.
NOTE:
In order to access the setup menu, use a terminal emulation program, which is
already installed on your computer.
If no such program is installed on your computer, you can also download the free
software PuTTY.
The following link provides a free download of this software:
http://www.chiark.greenend.org.uk/~sgtatham/putty/
Bits per second:
115.200
Data bits:
8
Parity:
none
Stop bits:
1
Flow control:
none
Setup Menu for Audio-Transceiver
Show Firmware Info
...
Set Fiber Line Info
...
Set System Defaults
...
Input:
Auto
SPDIF Output:
96 kHz
Show SPDIF Parameters:
...
'Space': Toggle 'S': Save
