Technical data
Audio-Transceiver-Fiber · 14
English
Technical data
General signal extender features
AUDIO-TRANSCEIVER
-FIBER
Analog audio
Audio connector:
1 × 3.5 mm jack plug (Line In)
1 × 3.5 mm jack plug (Line Out)
Sampling rate:
96kS/s (Line In)
192kS/s (Line Out)
Resolution:
24 bit
Bandwidth:
22 Hz - 22 kHz
Microphone pre-amplification
Max. 24 dB
Input voltage
Max. 1 Vrms
Output voltage
Max. 1 Vrms
Digital audio
Audio connector:
1 × RCA socket (Digital Audio – In)
1 × RCA socket (Digital Audio – Out)
Signal:
SPDIF, Consumer, PCM Stereo
Sampling rate:
44.1 - 192 kS (Digital Audio – In)
48; 96 or 192 kS (Digital Audio – Out)
Resolution:
24 bit
Bandwidth:
22 Hz - 22 kHz
Data transmission
between extenders
Interface:
1 × LC duplex socket
Transmission length:
see features of transmission
modules
Power supply
Type:
Portable power pack
Connector:
Mini-DIN 4 socket
Current consumption:
Max. 300 mA @ 12 VDC
Power consumption:
Max. 2.0 W @ 12VDC
Casing
Material:
Anodised aluminium
Dimensions (W × H × D):
105 × 26 × 84 mm
Weight:
Approx. 220 g
Operational
environment
Temperature:
+5 to+45 °C
Air humidity:
< 85%, non-condensing
Conformity
CE, RoHS
