Introduction
Diy vice
Q
Introduction
The instructions for use are to be considered as part of the
product. They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety information and
instructions for use. The product must only be used as described
and for the stated fields of application. If you pass the product on
to third parties, please give them all of the documentation as well.
Q
Intended Use
The product is intended for clamping small, light workpieces made
of wood or metal, e.g. for model-making, to hold them still while
further work is performed on them. Other uses or changes to the
product are considered to be contrary to the intended use and
may harbour risks of injury and damage. The manufacturer does
not accept any liability for injury or damage resulting from use of
this product contrary to its intended use. The product is not intended
to be used for commercial purposes.
Q
Description of parts and features
1 Jaw protectors
2 Jaws with V-grooves
3 Hexagonal socket head screw
4 Hexagonal socket head screw
5 Ball joint
6 Ball joint tommy bar
7 Clamping screw
8 Hexagonal socket head screw
9 Vice jaws tommy bar
10 Spindle
11 Vice base
