8 GB/CY
Use / Cleaning and care / Disposal
Q
Mounting the tube attachment
The tube attachment is intended for clamping tubes with a diameter
of 38 - 43 mm.
1. Release the hexagonal socket head screw 3 at the end of
the spindle using the supplied hexagon socket screw key 12 .
2. Turn the vice jaws tommy bar 9 anticlockwise until the
spindle 10 is turned out of the rear jaw 2 .
3. Using the supplied hexagon socket screw key 12 , release the
hexagonal socket head screw 8 on the underside of the vice
base 11 and remove the spindle 10 from the vice.
4. Now that the hexagonal socket head screw 4 is accessible,
remove it and take the vice base off the ball joint 5 .
5. Place the tube attachment 13 on to the ball joint 5 and
fasten it in place with the hexagonal socket head screw 4 .
6. Turn and tilt the ball joint 5 to achieve the right position.
Q
Cleaning and care
j Clean the product with a dry, fluff-free cloth.
j Never use aggressive or corrosive cleaning agents, as they
may damage the product.
Q
Disposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities.
Contact your local refuse disposal authority for more details of
how to dispose of your worn-out product.
