6 GB/IE
Safety advice / Operation
Safety advice
KEEP ALL THE SAFETY ADVICE AND INSTRUC-
TIONS IN A SAFE PLACE FOR FUTURE REFER-
ENCE!
 WARNING! DANGER OF
LOSS OF LIFE AND ACCIDENT
TO INFANTS AND CHILDREN!
Never leave children unsupervised with the pack-
aging materials. Danger of suffocation. Keep
out of the reach of children. It is not a toy.

Always keep the product out of reach of children.
Children often underestimate danger. Store the
device indoors in an enclosed, dry place where
it cannot be reached by children.

Ensure that staples and nails cannot under any
circumstances strike people or animals. Failure
to observe this advice may lead to injury.

Wear personal protective equipment and always
wear safety glasses. This also applies to people
who may be helping with the work by support-
ing or holding the workpiece.
 CAUTION! Do not support yourself with your
hands under any circumstances near or in front
the stapler gun or on the surface being tacked.
One slip may result in injury.

Every time before you use the device, check
that it is in perfect condition. Damage to any of
its components may lead to injury.

Check that all parts have been assembled and
fitted properly. Incorrect assembly or fitting
may lead to injury.

Remain alert at all times and always watch what
you are doing. Proceed with caution. Just one
moment of inattention during assembly may
lead to injury.

Before moving or putting away the stapler gun,
check that there are no staples or nails still in
the device.
 Operation
 Filling with staples / nails
 CAUTION! Use only the staples and nails
described in these operating instructions (see
“Staples / nails”). Failure to observe this advice
may result in damage to the device.
Note: You can use three different types of staples /
nails in the stapler gun; flat crown staples, round
crown staples and T-nails. All three types are sup-
plied with the stapler gun.
Follow these steps:
1. Press in the staple pusher
2 slightly and then
pull it downwards. Then pull the staple pusher 2
completely out of the magazine 4 (see Fig. A).
2. Push the staples or the T-nails into the maga-
zine 4 .
 CAUTION! Ensure that the staples or T-nails
are correctly inserted (see Figs. B, C, D).
3. Push the staple pusher 2 back into the maga-
zine 4 . Press in the staple pusher 2 slightly
and then pull it slightly upwards to fix it in place.
 Setting the impact force
 CAUTION! Never screw the adjusing screw
7
completely out of the stapler gun. This could
result in damage to the device.

Screw out the adjusing screw 7 to reduce
the impact force.

Screw in the adjusing screw 7 to increase
the impact force.
 Stapling
 CAUTION! Never support yourself by placing
your hands near or in front of the stapler gun
or the workpiece surface. A slip can result in
injury.
Follow these steps:
1. Press the staple eject opening
6 on the spot
where you wish to staple.
