Introduction
Description of parts
1
Precision engineer’s LED magnifying glass
2
Lens (magnification 2.5 / 5 times)
3
Battery compartment cover
4
Battery compartment
5
Ball joint
6
Retaining screw (lens ball joint)
7
Magnifying glass fixing clamp
8
Retaining screw (magnifying glass height adjustment)
9
On / off switch
10
Supporting rod (height adjustment)
11
Fixing clamp (repair device)
12
Retaining screw (repair device height adjustment)
13
Soldering iron holder
14
Base
15
Repair device
16
Retaining screw (repair device ball joint)
17
Retaining screw (repair device)
18
Alligator clips
19
Retaining screws (alligator clips)
20
LED lamps (Fig. B)
21
Batteries (Fig. C)
Technical Data
Operating voltage: 4.5 volts
Batteries:
3 x 1.5 V , AAA type
Max. power rating: 2 x 0.06 W
