5 GB/IE
Drill stand
Intended use
The product is designed for commercial drills and is
suitable for placing exactly defined holes at right-
angles into wood, metal and ceramic tiles. It is pos-
sible to mount the work-piece securely during
drilling. Consult the manufacturer‘s operating man-
ual before using the drill. The product is not in-
tended for commercial use.
Parts description
Drill stand:
1 Bolt
2 Lever arm
3 Drill holding fixture
4 Guide slot (4 x)
5 Drill hole (4 x)
6 Base plate
7 Pillar
8 Block
9 Slider
10 Locking screw
11 Drill depth gauge with indicator
12 Screw
Machine vice:
13 Machine vice
14 Long slot
15 Locking device
16 Quick-release button
17 Clamping jaw
Contents
1 Drill stand
1 Hexagon key
1 Machine vice
1 Operating instructions
Technical Data
Drill holding fixture for
clamping collar diameter: 43 mm
Drilling depth:
to 60 mm steplessly
adjustable
Dimensions: 155 x 505 x 225 mm
(W x H x D)
Clamping jaw width: 65 mm
Clamp width: 65 mm
Safety notes
YOU SHOULD STORE ALL SAFETY INFORMATION
AND INSTRUCTIONS IN A SAFE PLACE IN
CASE YOU NEED TO REFER TO THEM AGAIN
IN THE FUTURE!
CAUTION! RISK OF INJURY! When work-
ing with hand-operated electrical tool, slipping
or loosening of the mounted work-piece can
cause severe injuries. Therefore, never work on
a mounted work-piece using a hand-operated
electrical tool.
CAUTION! RISK OF SHEARING OR
CRUSHING INJURY! There is the risk of
shearing or crushing injuries while working with
the drill stand.
CAUTION! RISK OF INJURY! Pay attention
to flying chippings and splinters. There is the
risk of injury.
Keep out of the reach of children. Store the
product out of the reach of children.
Check the product for damage before each
use. Please do not use this device if you find
that it is damaged in any way.
Check that the screws are tight before each use.
Use the product on a solid, level and intact
surface (e.g. a workbench).
Always disconnect the drill from the power
supply before making adjustments or work
breaks.
Wear protective gloves and safety goggles.
The drill stand must be mounted on a workbench
or a stable, tilt-free table, to ensure a safe work.
Use the drill holes
5 in the base plate 6 .
