6 GB/IE
Assembly
Note: You need a 5mm hexagon key (provided),
two open-ended spanners (10 mm & 14 mm) and a
slot screwdriver (1.2 x 8.0 mm) for assembly and
adjustment.
Connect the pillar 7 to the base plate 6 .
Then fix the slider 9 on the pillar (see Fig. A).
Mount the lever arm 2 onto the slider (see Fig. B).
Tighten the screws and nuts as tight as possible.
Mount the machine vice 13 onto the base
plate. To do this connect the screws with the
guide slots
4 in the base plate through the two
long slots 14 (see Fig. C).
Note: The machine vice can be positioned
exactly by moving the guide slots and long slots.
Mounting the work-piece
Hold the quick-release button 16 pressed and
pull the locking device 15 back as far as it
goes (see Fig. D).
Place the work-piece into the machine vice 13 .
Press the quick-release button and push the
locking device with the clamping jaw 17
against the work-piece.
Fix the work-piece with a right turn (see Fig. E).
Clamping in and
adjusting the drill
Fit the drill with its clamping collar into the drill
holding fixture 3 and tighten securely (see Fig. F).
Insert a suitable drill bit into the chuck.
Unscrew
bolt 12 (see Fig. G).
Move the slider 9 with the clamped in drill on
the pillar 7 , until the drill nearly touches the
work-piece.
Retighten screw securely.
Adjusting the drill depth
Loosen the block 8 and slide it up to the
slider 9 (see Fig. H).
Loosen the locking screw 10 by turning it to the
left (see Fig. H).
Make sure that the bolt 1 will be released do-
ing this and slides down to the lowest position.
Move the lever arm 2 down and read off the
desired drill depth on the drill gauge with indi-
cator
11 .
Fix the locking screw 10 and block 8 with a
right turn (see Fig. I).
Adjusting the work piece
Loosen the fixing screws of the machine vice 13 .
Adjust the machine vice with the work piece by
sliding it into position.
Mark the exact position and punch a drilling
point on the work-piece. Retighten the machine
vice (see Fig. J).
Storage and care
Store the hexagon key in the fixture on the slider.
Store the product in a dry place, out of the
reach of children.
Clean the product with a damp cloth.
Lightly grease the moving parts, rub the plain
metal parts with an oily cloth to protect them
from rust.
Disposal
The packaging is made from environ-
mentally friendly materials, which may
be disposed through your local recy-
cling facilities.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.
