Powerfix PKRS 1.5 A1 - Handbuch (Seite 10)

7 PKRS 1.5 A1
GB
IE
Battery insertion/ exchange
This wax melter requires 2 x 1.5 V batteries, type
AA/LR6/Mignon, for operation.
♦ Open the battery compartment on the
underside of the wax melter .
♦ Place the batteries into the battery compart-
ment , following the polarity details as
depicted in it.
♦ Close and secure the battery compartment.
Operating elements
Wax melter
Wax melter tip
On/Off
switch
Activation button
Battery compartment
Cleaning scraper
Scraper with planer function
Scraper with curvature
Sanding
sponge
Cleaning cloth
Handling and operation
In this chapter you will receive important infor-
mation for the handling and operation of the
appliance.
Switching the appliance on/off
♦ To switch the appliance on, place the On/
Off switch at the position “ON”.
♦ Press and hold the activation button to
heat up the wax melter tip .
♦ To switch the appliance off , place the On/
Off switch at the position “OFF”.
Application example
Preparation (Fig. A)
♦ Clean the damaged area with the spatula
and remove all loose parts.
Colour selection (Fig. B)
♦ Select the matching colour tone. Ensure that
several colour tones, from light to dark, are
always used.
