Powerfix PKRS 1.5 A1 - Handbuch (Seite 11)

8 PKRS 1.5 A1
GB
IE
Melting and fi lling (Figs. C + D)
♦ Place the On/Off switch at the position
“ON” to switch the appliance on.
♦ Press and hold the activation button to
heat up the wax melter tip .
♦ Now melt small portions of the hard wax and
place them into the damaged area, until it is
slightly overfi lled. Start with the light colour
tones and progress step by step to the dark
colour tones.
Filling (Fig. E)
♦ For vertical surfaces it is recommended to mix
the colour tone beforehand, collect it on the
spatula and then fi ll the damaged area.
When working on curved areas the scraper
with curvature should be used to fi ll hard
wax into the damaged area.
Smoothing (Fig. F)
♦ Allow the hard wax to cool for a few seconds
(about 10 seconds).
♦ After cooling, smooth any protrusion with the
planing grooves of the scraper . Use only
light pressure to smooth the protrusion.
Fine matching (Fig. G)
♦ For fi ne matching, now imitate any marbling
with a darker colour tone.
♦ Subsequently, again smooth any protrusion
with the planing grooves of the scraper .
Degreasing (Fig. H)
♦ To fi nish, remove the last hard wax residues
with the sanding sponge . Thereby the
gloss level of the surface will also be simulta-
neously matched. Job done!
Cleaning the planer grooves (Fig. I)
♦ Place the cleaning scraper on the cooled
wax melter tip and scrape the wax resi-
dues from the plane grooves.
