Einstellung dip-switches rs422 – BECKHOFF CX1000 Benutzerhandbuch
Seite 26
Produktübersicht
24
Embedded-PC
RS485 without Echo, Drop-Point ( without Termination)
DIP
Status
Funktion
1
off
Echo on
2
on
Echo off
3
on
Auto send on
4
off
Always send on
5
off
Auto receive on
6
on
Always receive on
7
off
Term on
8
off
Term on
RS485 with Echo, Drop-Point ( without Termination)
DIP
Status
Funktion
1
on
Echo on
2
off
Echo off
3
on
Auto send on
4
off
Always send on
5
off
Auto receive on
6
on
Always receive on
7
off
Term on
8
off
Term on
Einstellung DIP-Switches RS422:
RS422 full duplex end point
DIP
Status
Funktion
1
on
Echo on
2
off
Echo off
3
off
Auto send on
4
on
Always send on
5
off
Auto receive on
6
on
Always receive on
7
on
Term on
8
on
Term on
Die Dip-Schalter für die Konfiguration der RS485/422 Schnittstelle befinden sich an der linken Seite des Moduls.
Nach dem Entfernen der grauen Abdeckung wird der Schalter sichtbar.
