3 · G&D CATCenter NEO4
The matrix switch CATCenter NEO4
The matrix switch CATCenter NEO4 enables to control up to 32 target modules
using 4 user modules. By cascading, the number of target computers can be in-
creased to 2048.
Both the target computers as well as the user modules are connected to the
CATCenter system through category 5 (or better) twisted pair cables.
The user modules are connected to the CATCenter system using the user module
UCON. Monitor, keyboard and mouse are connected to the user modules.
The user module UCON-IP-eco additionally enables the user to operate the target
computers connected to the CATCenter system over a TCP/IP connection.
The target computers are connected to the CATCenter system using CATpro2 target
modules. The target modules optimise the signals for transmitting via Category 5
(or better) twisted pair cables.
