Installation Guide
5 · G&D CATCenter NEO4
Installation
The installation does not require any changes on the target computers. It is mainly
limited to plugging cables and can therefore be carried out by the user. All connec-
tions are located at the back of the device.
Important: The total length of the twisted pair cabling between a CATpro2 target
module and a UCON-a user module must not exceed 100 metres, or 300 metres
when using the user modules UCON or UCON-s.
Connecting the target computers
Connection via the target module CATpro2-PS/2
How to connect the target module CATpro2 to the matrix switch:
 Unplug the monitor, keyboard and mouse cables from the interfaces of the
target computer.
 Insert the 15-pin sub HD plug of the target module into the VGA interface of
the target computer to be connected.
 Connect the two PS/2 plugs of the target module to the keyboard (purple) or
mouse interface (green) of the target computer to be connected.
 Insert one end of the category 5 (or better) twisted pair cable into the RJ45
socket of the target module.
 Connect the other end of the twisted pair cable to a CPU interface (RJ45 socket)
of the matrix switch CATCenter NEO4.
Connection via the target module CATpro2-USB
How to connect the target module CATpro2-USB to the matrix switch:
 Unplug the monitor, keyboard and mouse cables from the interfaces of the
target.
 Insert the 15-pin sub HD plug of the target module into the VGA interface of
the target computer to be connected.
 Insert the USB-A plug of the target module into a free USB-A port of the target
computer.
 Insert one end of the category 5 (or better) twisted pair cable into the RJ45
socket of the target module.
 Connect the other end of the twisted pair cable to a CPU interface (RJ45 socket)
of the matrix switch CATCenter NEO4.
