Installation Guide
7 · G&D CATCenter NEO4
Connection via the CATpro2-SUN-USB target module
The target module CATpro2-SUN-USB is available in two versions (German and
American keyboard layout).
If a keyboard with American keyboard layout is applied at the user module, the
target module CATpro2–SUN-USB-US has to be used to connect the Sun computer.
If a keyboard with German layout is connected to the user module, proceed ac-
cordingly.
How to connect the target module CATpro2-SUN-USB to the matrix switch:
 Unplug the monitor, keyboard and mouse cables from the interfaces of the
target computer.
 Insert the 15-pin sub HD plug of the target module into the VGA interface of
the target computer to be connected.
 Insert the USB-A plug of the target module into a free USB-A port of the target
computer.
 Insert one end of the category 5 (or better) twisted pair cable into the RJ45
socket of the target module.
 Connect the other end of the twisted pair cable to a CPU interface (RJ45 socket)
of the matrix switch CATCenter NEO4.
Connection via the target module CATpro2-VT100
How to connect the target module CATpro2-VT100 to the matrix switch:
 Connect the VT-100 device to the target module CATpro2-VT100. Use a serial
cable for this purpose.
 Insert one end of the category 5 (or better) twisted pair cable into the RJ45
socket of the target module CATpro2-VT100.
 Connect the other end of the twisted pair cable to a CPU interface (RJ45 socket)
of the matrix switch CATCenter NEO4.
