Installation Guide

G&D CATCenter NEO4 · 24

Back panel

Every RJ45 interface at the back panel of the user module UCON-s provides addi-
tional status LEDs. These LEDs have the following function:

Section LED Meaning

yellow

The port is currently occupied by a user.

CPU

green

Connected to the CATpro2 target module.

yellow

The port is currently occupied by a user.

Trans-

mission

green

Connected to the CATCenter system.
