Installation Guide
G&D CATCenter NEO4 · 26
Technical data
Matrix switch CATCenter NEO4
Console ports
per device:
4
per device:
32
Cascade level 1:
256
Target ports
Cascade level 2:
2048
to user module:
dedicated CAT-x connection
Transmission type
to target module:
dedicated CAT-x connection
Type:
internal power pack
Connection:
IEC plug (IEC-320 C14)
Voltage: AC100-240V/60-50Hz
Current consumption:
0,12A@240VAC/0,25A@100VAC
Main power
supply
Power consumption (max.):
15,7W@240VAC/15,3W@100VAC
Type:
external power pack
Connection:
miniDIN-4 power plug
Voltage:
12VDC
Current consumption:
1,2A@12VDC
Redundant power
supply
Power consumption (max.):
12,9W@12VDC
Material: anodised
aluminium
Dimensions (W × H × D):
desktop: 435 × 88 × 286 mm
rackmount: 19” × 1HU × 286 mm
Casing
Weight:
approx. 3 kg
Temperature:
+5 to +45 °C
Operational
environment
Air humidity:
< 80%, non-condensing
to user module:
4 × RJ45 socket
to target module:
32 × RJ45 socket
for network connection:
2 × RJ45 socket
for update:
not required
(via web application Config Panel)
Interfaces
for powerswitch:
1 × RJ11 socket
Conformity
CE, RoHs
