33 · G&D CATCenter NEO4
User module UCON-IP-eco
Signal type: analog video
video resolution:
(local connection) max. 1920 × 1440 @ 75 Hz
(depending on cable length)
Graphics
video resolution:
(over native IP) max. 1280 × 1024 @ 75 Hz
(depending on cable length)
Distance between user module
and target module:
max. 300 m
Transmission type to user
module:
dedicated CAT-x connection
Transmission type to
KVM-IP client:
TCP/IP protocol
Communication: Ethernet 10/100 Mbit/s
Transmission
Delay compensation: yes
Number: 2 (concurrent: 1 × IP; 1 × local) Workstations
Occupied console ports at
central module:
1
Type: internal power pack
Connection: IEC plug (IEC-320 C14)
Main power
supply
Voltage: AC100-240V/60-50Hz
Type:
external power pack
Connection: miniDIN-4 power socket
Redundant
power supply
Voltage: +12VDC
Material: anodised aluminium
Dimensions (W × H × D):  desktop: 435 × 44 × 356 mm
 rackmount: 19” × 1HU × 356 mm
Casing
Weight: approx. 3,0 kg
Temperature: +5 to +45 °C Operational
environment
Air humidity: < 80%, non-condensing
1 × D sub HD 15 socket (video)
for user module:
2 × PS/2 socket (keyboard/mouse)
to matrix switch: 1 × RJ45 socket
for network: 1 × RJ45 socket
Interfaces
for update: not required
(over network interface)
Conformity CE, RoHs
