Installation Guide
G&D CATCenter NEO4 · 28
Target module CATpro2-Audio-PS/2
Graphics
Signal type:
analog video
Resolution: 24
bit
Sampling rate:
48 Hz
Audio
Bandwidth 20
kHz
Total length
Target module incl. cable
0,3 m
Type:
via keyboard interface
of target computer
Connection: PS/2
Power supply
Voltage: +5VDC
Material:
plastics
Dimensions (W × H × D):
45 × 20,7 × 70 mm
Design:
converter
Casing
Weight:
approx. 140 g
Temperature:
+5 to +45 °C
Operational
environment
Air humidity:
< 80%, non-condensing
to target computer:
2 × PS/2, 1 × D-Sub HD 15,
1 × audio jack
Interfaces
to matrix switch:
1 × RJ45 socket
Conformity
CE, RoHs
Target module CATpro2-Audio-USB
Graphics
Signal type:
analog video
Resolution: 24
bit
Sampling rate:
48 Hz
Audio
Bandwidth 20
kHz
Total length
Target module incl. cable
0,3 m
Type:
via keyboard interface
of target computer
Connection: USB
Power supply
Voltage: +5VDC
Material:
plastics
Dimensions (W × H × D):
45 × 20,7 × 70 mm
Design:
converter
Casing
Weight:
approx. 120 g
Temperature:
+5 to +45 °C
Operational
environment
Air humidity:
< 80%, non-condensing
to target computer:
1 × USB-A, 1 × D-Sub HD 15,
1 × audio jack
Interfaces
to matrix switch:
1 × RJ45 socket
Conformity
CE, RoHs
