Installation Guide
G&D CATCenter NEO4 · 32
User module UCON-s
Signal type: analog video Graphics
video resolution:
(local connection) max. 1920 × 1440 @ 75 Hz
(depending on cable length)
Distance between user module
and target module:
max. 300 m
Transmission type to
user module:
dedicated CAT-x connection
Transmission
Delay compensation: yes
Number: 1
Occupied console ports at
central module:
1
User consoles
Additionally connectable
console computers:
2
Type: internal power pack
Connection: IEC plug (IEC-320 C14)
Main power
supply
Voltage: AC100-240V/60-50Hz
Type:
external power pack
Connection: miniDIN-4 power socket
Redundant
power supply
Voltage: +12VDC
Material: anodised aluminium
Dimensions (W × H × D):  desktop: 270 × 44 × 211 mm
 rackmount: 19” × 1HU × 211 mm
Casing
Weight: approx. 1,3 kg
Temperature: +5 to +45 °C Operational
environment
Air humidity: < 80%, non-condensing
1 × D-Sub HD 15 socket (video)
2 × PS/2 socket (keyboard/mouse)
for user modules:
2 × USB-A socket (keyboard/mouse)
to matrix switch: 1 × RJ45 socket
for local computer:
(with target moduleCATpro2)
2 × RJ45 socket
Interfaces
for update: 1 × 2,5 mm phone jack
Conformity CE, RoHs
