Target modules
»
CATpro2-DVI-Audio
G&D CompactCenter X2 · 31
Technical data
Interfaces to
computer:
Video:
1 × DVI-D (single link)
Keyboard and mouse signals:
1 × USB-B
Power supply:
1 × USB-B
Audio:
1 × 3,5 mm jack plug
Interfaces to
KVM matrix switch
Data transmission:
1 × RJ45 (KVM matrix switch #1)
1 × RJ45 (KVM matrix switch #2)
Video
Resolution @ 60 Hz:
max. 1920 × 1200 pixels
Resolution @ 85 Hz:
max. 1280 × 1024 pixels
Colour depth:
24 bit
Pixel rate:
25 MHz to 165 MHz
Vertical frequency:
50 Hz to 180 Hz
Horizontal frequency:
30 kHz to 130 kHz
Norms:
DVI 1.0, E-DDC
Audio
Type:
transparent, uni-directional
Resolution:
24 Bit
Sampling rate:
48 kHz
Bandwidth:
20 kHz
Power supply
Standard
Type:
through two USB interfaces
Connection:
2 × USB-B (High Power)
Current consumption:
max. 700 mA over two USB interfaces
(max. 500 mA per 5 V-USB)
Power supply
Optional
Typ:
AC adapter (12 V/2 A)
Connection:
Mini-DIN 4 socket
Current consumption:
max. 350 mA@12 VDC
No. of devices per AC adapter:
max. 4 devices via Power Loop cables
Power input
Standby:
0,5 W@2 × 5 V-USB; 0,5 W@12 V
Operation:
3,4 W@2 × 5 V-USB; 3,8 W@12 V
Casing
Material:
anodised aluminium
Dimensions (W × H × D):
105 × 26 × 84 mm
Weight:
approx. 210 g
Operating
environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
