TEILELISTE
6/13/95
HT4001 Betriebsanleitung 7-21
Gaskonsole (073216)
Teile-
Position nummer Beschreibung bestimmt für Menge
073216 HT4001 Gas Console III
1 001335 Encl: HT400X/2000 Gas Csl 1
129089 Front Pnl SA HT4001 Gas Csl III 1
2 001463 Pnl:HT4000 Gas Cnsl II Front 1
3 004117 Cap:Needle Valve 3
4 005042 Tgl Sw: SP MOM ON/OFF/ON S3 1
5 005181 Tgl Sw: DPDT Maint ON/NONE/ON S1 1
6 005180 Tgl Sw: SP3T Maint ON/OFF/ON S2 1
7 005243 PressSw:80 PSI 1/8 NPT PS1 1
8 005243 PressSw:80 PSI 1/8 NPT PS2 1
9A 006109 Sol Valve: 150# Manif 120V 2-Way NC SV1A 1
9B 006109 Sol Valve: 150# Manif 120V 2-Way NC SV1B 1
10 006109 Sol Valve: 150# Manif 120V 2-Way NC SV2 1
11 006109 Sol Valve: 150# Manif 120V 2-Way NC SV3 1
12 006064 Meter Valve:1/8 FPT .125 Orf MV2 1
13 006064 Meter Valve:1/8 FPT .125 Orf MV3 1
14 006064 Meter Valve:1/8 FPT .125 Orf MV4 1
15 011069 Flowmeter:1.9 SCFM/3F9 Flt (No-V) FM3 1
16 011056 Flowmeter:0-10 SC/BT-8 Flt Cal 2% FM1 1
011057 Flowtube/BT-8 Float:0-10 SC Cal. 2% 1
011081 Float Stop 1
011008 Shield, Plastic, 63S0503M0010 1
17 011053 Flowmeter:0-10 SC/BP-8 Flt Cal 2% FM2 1
011058 Flowtube/BP-8 Float:0-10 SC Cal. 2% 1
011081 Float Stop 1
011008 Shield, Plastic, 63S0503M0010 1
18 015135 Insert, 1/8 OD Brass 6
19 015136 Adapter: 1/8 FPT X 1/8 CPRSN 90 3
20 015139 Adapter: 1/4 FPT X 1/4 CPRSN 90 1
21 015608 Sleeve, Delrin 1/4" OD 10
22 015609 Insert Brass 1/4 plastic tube 10
23 022020 Press Gauge:160#/Bar 2" 1/8CBM PG1 1
24 022020 Press Gauge:160#/Bar 2" 1/8CBM PG2 1
25 022024 Press Gauge:200#/Bar 2" 1/8CBM PG3 1
26 046048 Tubing, 1/8 OD Blk Air Brake 1.6ft
27 046078 Tubing, 1/4 OD X .040 Blk Nyl 3.4ft
28 015299* Filter:.10 Micron 1/8FPT Brass Inline 2
004717** Manifold, Gas Console 1
129165 Harness:HT4001 III Gas Console 1
008208 Rcpt Shell:CPC 23-37 Rvs Sex 3X1 1
008176 Pin:24-20 AWG Type III + CRP 20
008447 Rcpt Shell:CPC 23-37 Std Sex 3X2 1
008186 Skt:24-20 AWG Type III + CRP 11
* Liegt hinter den Druckschaltern
** Liegt hinter den Magnetventilen
