TEILELISTE
6/13/95
HT4001
Betriebsanleitung
7-23
Motor-Ventil-Konsole (073214)
Teile-
Position
nummer
Beschreibung
bestimmt für
Menge
073214
HT4001 Motor Valve Console
1
002218
Encl: 2000/400X Mtr Valve Csl
1
2A
006109
Sol Valve: 150# Manif 120V 2-Way NC
SV4A
1
2B
006109
Sol Valve: 150# Manif 120V 2-Way NC
SV4B
1
3
006063
Mtr Valve: Elec 1/8FPT .125 orf
MV1
1
4
015050
Adapter, 1/8FPT X 1-1/2
3
5
015116
Adapter, 1/8 NPT X RH 'A'
1
6
015210
Adapter, 1/8 NPT X LH 'A'
1
7
015530
Street Elbow 1/8 90
1
8
015588
Nipple, 1/8 X 2"
1
9
015608
Sleeve, Delrin 1/4" OD
6
10
015609
Insert Brass (1/4 OD)
6
11
015611
Adapter, 1/8NPT X 1/4 CPRSN
2
12
015612
Adapter, 1/8NPT X 1/4 CPRSN 90
3
13
029759
Harn: HT400X Mtr Valve Csl
1
14
008210
Rcpt Shell: CPC 11-4 Rvs Sex
4X2
1
15
008447
Receptacle, 23-37, Std Sex CPC
4X1
1
029765
Wire GP: HT400X Mtr Valve Csl
1
16
008176
Pin: 24-20 AWG Type III + CRP
3
17
008186
Skt: 24-20 AWG Type III + CRP
4
18
015299
Filter:.10Micron 1/8FPT Brass Inline
1
19
004718
Manifold: Motor Valve
1
