TEILELISTE
6/13/95
HT4001
Betriebsanleitung
7-47
Empfohlene Verschleißteile
Stromquelle
Seiten-
Teilenummer
Beschreibung
bestimmt für
Menge
verweis
005149
Bulb: 120VAC T2
LT1,LT2
2
7-4
027080
Fan: 225CFM 120VAC 50/60 Hz
M1-M4,M6
1
7-4
027079
Fan: 450-550 CFM 120VAC 50/60 Hz
M5, M7
1
7-4
041588
PCB Assy: HT4001 Control Board II
PCB2
1
7-4
081038
Firmware: HT4001
2
7-4
041246
PCB Assy: 2000/HD Relay
PCB4
1
7-4
041359
PCB Assy: HT4001 750A THC Mother
PCB12
1
7-16
041358
PCB Assy: HT4001 750A THC
PCB13
1
7-16
008317
Fuse: 125 Amp, 250V
F1-F4
4
7-8
003217
Contactor: 170A 3Ø, 120VAC
CON1
1
7-16
003152
Circuit Breaker; 2 Pole 5A 600V 100ma
CB1
1
7-14,7-16
041534
PCB Assy: Power Distribution
PCB1
1
7-10
041536
PCB Assy:200/4x0x/HD Interlock
PCB5
1
7-4
129160
CH100-CE/LVD Chopper SA
CH1-CH4
1
7-6
109004
Current Sensor:Hall 100A=4V
CS1-CS4
2
7-10
109005
Current Sensor:Hall 1000A=4V
CS5
1
7-10
Hochfrequenz-Konsole
009280
Cap: .002µF 15 15kV
C5A,C5B
2
7-18
004061
Electrode:Sprk Gap 1/8 x 1.6
3
7-18
029902
HV Transformer SA
T1
1
7-18
005139
Flowswitch:0.25 GPM SPST 1/4 NPT
FS2
1
7-18
005140
Flowswitch:1.20 GPM SPST 1/4 NPT
FS1
1
7-18
006031
Solenoid Valve:350# 1/4 FPT 120V NC
SV6
1
7-18
003149
Relay:120VAC 2PDT NO/NC
CR1
1
7-18
009795
Diode: 1200V 20A
D1
1
7-18
Gaskonsole
005162
Pressure Switch:0-200psi 1/8 NPT
PS1,PS2
1
7-20
006109
Solenoid Valve: 150# 1/8FPT 120V 2WNC
SV1A-SV3
1
7-20
011056
Flowmeter: 0.45 GPM/1.9SCFM
FM1
1
7-20
011057
Flow tube/BT-8 Float: 0-10 SC Cal. 2%
1
7-20
011081
Float Stop
1
7-20
011053
Flowmeter: 7.8 GPM/44CFH
FM2
1
7-20
011058
Flow tube/BP-8 Float: 0-10 SC Cal. 2%
1
7-20
011081
Float Stop
1
7-20
011008
Shield: Plastic, for 011053 or 011056
1
7-20
011069
Flowmeter:1.9 SCFM/SF-11 Flt
FM3
1
7-20
022020
Gauge: Pressure:160#/Bar 2"
PG1,PG2
1
7-20
022024
Gauge: Pressure:200#/Bar 2"
PG3
1
7-20
