Drehgeber mit ProfiNet-Schnittstelle
16
8.5 Standard- und Herstellertelegramme
Standardtelegramm 81
IO-Daten
(Doppel-Wort)
1
2
Sollwert
STW2_ENC *
G1_STW1 *
IO-Daten
(Doppel-Wort)
1
2
3
4
5
6
Istwert
ZSW2_ENC*
G1_ZSW1*
G1_XIST1*
G1_XIST2*
Standardtelegramm 82
IO-Daten
(Doppel-Wort)
1
2
Sollwert
STW2_ENC*
G1_STW1 *
IO-Daten
(Doppel-Wort)
1
2
3
4
5
6
7
Istwert
ZSW2_ENC*
G1_ZSW1*
G1_XIST1*
G1_XIST2*
NIST_A*
Standardtelegramm 83
IO-Daten
(Doppel-Wort)
1
2
Sollwert
STW2_ENC*
G1_STW1 *
IO-Daten
(Doppel-Wort)
1
2
3
4
5
6
7
8
Istwert
ZSW2_ENC*
G1_ZSW1*
G1_XIST1*
G1_XIST2*
NIST_B*
Standardtelegramm 84
IO-Daten
(Doppel-Wort)
1
2
Sollwert
STW2_ENC*
G1_STW1 *
IO-Daten
(Doppel-Wort)
1
2
3
4
5
6
7
8
9
10
Istwert
ZSW2_ENC*
G1_ZSW1*
G1_XIST3*
G1_XIST2* NIST_B*
* Details zu den Variablen → Kapitel 8.4
Herstellertelegramm 860
