TEST
TIMING DIAGRAM
(FOR O2 PLASMA GAS ONLY)
RUN
Time
O sec Plasma
START
SV2
Transfer
Start Complete
PREFLOW
Ramp UP Plasma
STOP Complete
OPERATE
Ramp DOWN
Test Switch
ON
PREFLOW
OFF ON
CUTFLOW
OFF
SV3
SV5
SV9,SV10
SV6
SV11,SV12
t2
t4
SV4
Pressure
(at nozzle)
t5
SV3
Solenoid Valve, O2 Gas Select SV2
Solenoid Valve, Air Gas Select
SV5
SV9,SV10
SV6
SV4
SV11,SV12
Solenoid Valve, CH4 Shield Gas Select
Solenoid Valve, N2 Shield Gas Select
Solenoid Valve, N2 Plasma Gas Select
Solenoid Valve, Shield Gas Operate
Solenoid Valve, Preflow Gas Operate
t6
Current
Pressure
(at shield)
Voltage
2 s
Note: All "t" times are SET current dependent
SV7,SV8
SV7,SV8 Solenoid Valve, Plasma Gas Operate
Machine
Motion
t3
Solenoid Valve, H35 Plasma Gas Select SV1 t2 = Transfer to Shield Gas
t3 = Transfer to Machine Motion
t4 = Transfer to Plasma Gas
t5 = Torch Ramp-Down (Gas & Current)
t6 = Ramp-up of Current From Pilot to Operate Current
t7 = Optional Pierce Complete
SV1
t7
Complete
Pierce
Transfer
Signal
to CNC
Optional
SV14
SV15
SV16 SV16
SV15
SV11,SV12
SV14
SV9,SV10
SV7,SV8
SV5
SV4
SV6
SV3
SV2
SV1
Solenoid Valve, Shield Preflow/Operate SV16
SV15 Solenoid Valve, Palsma Preflow/Operate
Solenoid Valve, Shield Gas Vent SV14
4 3 2 1
A
B
C
D
4 3 2 1
A
B
C
D
