7/10/98
INSTALLATION
HD3070
mit automatischer Gaskonsole Betriebsanleitung
3-5
38.25 in.(972 mm)
Stromquelle
Gas-
konsole
36 in.
(914 mm)
10 in.
(254 mm)
24.25 in.(616 mm)
22 in. (559 mm)
Abbildung 3-1
HD3070 Stromquelle mit automatischer Gaskonsole – Aufstellungsabmessungen
24 in. (610 mm)
