STANDARD-KOMPONENTEN
20
HySpeed HT2000
Betriebsanleitung
9-17
HT2000-Stromquelle
ቢ
: Hochfrequenz- und Eingabe-/Ausgabe-Karten-Bausatz
Teile-
Position
nummer
Beschreibung
bestimmt für
Menge
029514
HF & I/O PCB SA Pwr Sup/RHF
1
1
004136
Connector, cathode
1
2
004311
Standoff, MAX200 Anode
1
3
004312
Standoff, MAX200 Cathode
1
4
004313
Spacer, .42ID X .750 X .50 lg
1
5
004314
Block, MAX200 Cathode
1
6
015131
Fitting, 3/8 Tube X 1/4 NPT
1
7
015132
Fitting, 90, 3/8 Tube X 1/4 NPT
1
8
015133
Ferrule, 3/8 OD Tube Delrin
2
9
015015
Adapter, 90 1/4 NPT X #6
2
10
015532
Street Elbow 1/4
1
11
041152
Panel, MAX200 Output
1
12
075153
Hexnut, 3/8-16, Finish, Brs
10
13
075156
Hexnut, 1/2-20, Finish/Jam, Brs
1
14
075194
Lkwshr, 3/8, Splitlock, Brz
9
15
075217
Flwshr, 3/8, .390,.875,.063, Brs
2
16
075335
M/S, 8-32 X 1/2, SL, Bin, Nyl
3
17
075347
Bolt, 5/16 X 11/4, Hex, Brz
1
18
075229
Bolt, 3/8-16 X 1 1/2, FTH, Hex, Brs
1
19
075351
Bolt, 3/8-16 X 1, Hex, Brs
1
20
075360
Flwshr, 5/16, .328,.520,.032, Brs
1
21
075361
Flwshr, 3/8, .394, .625, .032, Brs
2
22
009356
Coil, A.C.T., 8G THHN
T1
1
23
041145
PC BD Assy MAX200 I/O
PCB8
1
24
029202
Current Sensor SA
CS1
1
25
015134
Insert, 3/8 OD X .062 Brass
2
26
075072
M/S, 8-32 X 1/2
6
