STANDARD-KOMPONENTEN
20
HySpeed HT2000
Betriebsanleitung
9-29
Fernsteuerung – Spannung/Strom
ቦ
:
Digitale Steuerungsstation Nr. 073007
Teile-
Position
nummer
Beschreibung
bestimmt für
Menge
073007
Control Station, Digital Remote V/C MAX200
1
1
002107
Cov: DR/PR V/C Top
1
2
002106
Cov: DR/PR V/C Bottom
1
3
002119
Panel, Rear, DR V/C
1
4
004119
Bracket, Mtg, DR/PR V/C
1
5
008069
Fuse, 3/8 Amp 313, 375
1
6
008165
Fuseholder, REM V/C
1
7
008164
Knob
2
8
014012
Transf'mer, DR/PR/SR V/C
1
002118
Encl, Assy DR V/C
1
9
001133
Pl: HT400 DR V/C MDL FR
1
10
001131
Flg: HT400 DR/PR V/C MDL Fr
1
11
001137
FR: HT400 DR/PR/ST V/C Mdl LS
1
12
001138
FR: HT400 DR/PR/ST V/C Mdl RS
1
029302
Filter PNL-PCB SA DR/SR V/C
1
13
009871
Potentiometer, 500 Ohm 10 turn
2
14
008175
Receptacle, Shell Size 13-9
1
15
008176
Pin, 20-24 AWG Type III+
6
074016
Term 22-18 .250 FEM QC Insul
2
074038
Term 22-18 FEM QC Insul
11
074041
Term 22-18 #6 Ring Uninsul
1
074067
Term 22-18 .25 MAL QC Insul
2
16
041070
PC BD Assy Opto-Iso
1
008097
Terminal, PC HHS 2022C
4
17
041187
PC BD Assy Dig/Sta V/C MAX200
1
18
004116
Heatsink, DR/PR SR V/C
1
19
042059
IC, LM340AK-5.0
1
20
009274
Capacitor, 2600 UF 15VDC
1
008097
Terminal, PC HHS 2022C
11
008098
Terminal, PC CAM
9
21
041076
PC BD Assy Rem Volt Disp
1
22
041077
PC BD Assy Rem Curr Disp
1
