ND 780
51
I - 3 Milling Specific Oper
ations
Touch workpiece edge.
Store the position of the edge by pressing the NOTE
soft key.The NOTE soft key is useful when
determining tool data by touching the workpiece in
the absence of an edge finder with feedback. To avoid
losing the position value when the tool is retracted,
press the NOTE soft key to store the value while it is
in contact with the workpiece edge. The location for
the touched edge will take into account the diameter
of the tool in use (T:1, 2...) and the last direction the
tool was moved
prior to pressing the NOTE soft key.
Retract the tool from the workpiece.
Enter coordinate of the edge
and
press ENTER.
PROBE IN X
ENTER VALUE FOR X
