Example 2: Rotary axis with degrees decimal display
C = + 1260.0000°
1
Coordinate axis
2
Equal sign
3
+/– sign
4
4 to 8 places before the decimal point
5
Decimal point
6
0 to 4 places after the decimal point
7
Blank space
8
W for angle (in distance-to-go display: w)
9
Carriage return
10
Blank line (Line Feed)
Example 3: Rotary axis with degrees/minutes/seconds display
C = + 360° 23' 45'' '
1
Coordinate axis
2
Equal sign
3
+/– sign
4
3 to 8 places degrees
5
Colon
6
0 to 2 places minutes
7
Colon
8
0 to 2 places seconds
9
Blank space
10
W for angle (in distance-to-go display: w)
11
Carriage return
12
Blank line (Line Feed)
C
=
+
1 2 6 0
.
0 0 0 0
W <CR>
<LF>
1
2
3
4
5
6
7
8
9
10
C = + 3 6 0
:
2 3
:
4 5
W
<CR>
<LF>
1
2
3
4
5
6
7
8
9
10
11
12
