Example 6: Probing function Circle Center

First center point coordinate, e.g. CCX = –1616.3429 mm, Second

center point coordinate, e.g. CCY = +4362.9876 mm, (Circle Center
X

axis, Circle Center Y axis; coordinates depend on working plane)

Circle diameter DIA = 1250.0500 mm

1

Colon

2

+/– sign, or blank space

3

2 to 7 places before the decimal point

4

Decimal point

5

1 to 6 places after the decimal point

6

Unit: blank space for mm, " for inches

7

R for radius display, D for diameter display

8

Carriage return

9

Blank line (Line Feed)

CCX

:

-

1 6 1 6

.

3 4 2 9

R <CR>

<LF>

CCY

:

+ 4 3 6 2

.

9 8 7 6

R <CR>

<LF>

DIA

:

1 2 5 0

.

0 5 0 0

R <CR>

<LF>

1

2

3

4

5

6

7

8

9
