»DL-Compact« KVM extender
3 · G&D DL-Compact
»DL-Compact« KVM extender
The DL-Compact KVM extender transmits dual link video signals (DVI-D) as well as
keyboard and mouse signals via two fibre optics.
The system consists of the following components:
 transmitter (DL-Compact-CPU)
 receiver (DL-Compact-CON)
The signals of the computer that is connected to the transmitter can be transmitted
to the console at the receiver over distances of up to 400 metres.
The bridgeable distance depends on the specifications and the quality of the fibre
optics:
Scope of delivery
 1 × transmitter (DL-Compact-CPU)
 1 × receiver (DL-Compact-CON)
 1 × video cable (DVI-D-DL-M/M-2)
 1 × USB device cable (USB-AM/BM-2)
 1 × twin PS/2 cable (Twin-PS/2-M/M-2)
 1 × service cable (USB-Service-2)
 2 × power pack (Power-Set 12-Typ 3)
 2 × power cable (PowerCable-2 Standard)
 1 × manual »Installation and Configuration«
TYPE DIAMETER CLASS DISTANCE
Multimode 50/125 μm OM2 400 meters
Multimode 62,5/125 μm OM1 200 meters
