Technical data
G&D DL-Compact · 20
Technical data
GENERAL FEATURES
Graphics
Colour depth:
24 bits
Max. resolution:
1920 × 1200 @ 60 Hz (single link)
2560 ×1600 @ 60Hz (dual link)
Vertical frequency:
20 Hz to 120 Hz
Horizontal frequency:
25 kHz to 130 kHz
Pixel rate:
165 MHz (single link)
330 MHz (dual link)
Main power supply
Type:
power pack
Connection:
Mini-DIN 4 socket
Voltage:
12VDC
Operating environment
Temperature:
+5 to +45 °C
Air humidity:
< 80%, non-condensing
TRANSMITTER (DL-COMPACT-CPU)
Interfaces
to computer
Video:
1 × DVI-D socket
PS/2 keyboard/mouse:
2 × PS/2 socket
USB keyboard/mouse:
1 × USB-B socket
Interfaces for
transmission
Video and input devices: 2 × LWL SC
Current consumption
Operation
Main power supply:
300 mA @ 12VDC
Casing
Material:
anodised aluminium
Dimensionen (W × H × D): 105 mm × 26 mm × 104 mm
RECEIVER (DL-COMPACT-CON)
Interfaces for
console
Monitor:
1 × DVI-D socket
Keyboard:
1 × PS/2 socket
1 × USB-A socket
Mouse:
1 × PS/2 socket
1 × USB-A socket
Interfaces for
transmission
Video and input devices: 2 × LWL SC socket
Current consumption
Operation
Main power supply:
600 mA @ 12VDC
Casing
Material:
anodised aluminium
Dimensions (W × H × D): 105 mm × 26 mm × 104 mm
