Configuration
G&D DL-Compact · 12
Operating the setup menu
The setup menu lists all KVM extender settings in tabular form:
The current setting of the different functions is displayed in the right column. The
three dots in the right column indicate that this particular function provides a sub
dialogue.
Starting and exiting the setup menu
How to start the setup menu:
1. Start the terminal emulation program.
2. Load the connection settings of the setup menu and start the connection.
3. Press the
R
key in the terminal emulation program.
How to exit the setup menu:
1. Press the key combination
Ctrl+X
twice to exit the setup menu.
Setup Menu for DL-Compact-CPU
Show System Info
...
Set System Defaults
...
Scancode Set:
2
PS/2 Keyboard Type:
Standard
USB Keymode:
PC Multimedia
EDID Mode:
Auto
'Space': Toggle 'S': Save
IMPORTANT:
Before starting the setup menu make sure that the Service interface of
the receiver or the transmitter is connected to the USB interface of the computer.
NOTE:
As soon as the connection has been successfully established, the setup
menu (see figure above) is displayed in the terminal emulation program.
IMPORTANT:
After the setup menu has been exited, the console monitor displays
no image until the Service cable is removed from the Service socket.
