Installation
G&D DVIVision-USB 2.0 · 4
Installation
Preparation
1. When choosing a place for the device, please ensure to comply with the ambient
temperature limit (see Technical Data on page 19 ff.) close to the device. The
ambient temperature limit must not be influenced by other devices.
2. Turn off the computer to be connected to the KVM extender and unplug the
cables of monitor, keyboard and mouse from the interfaces.
3. Place the computer module (DVIVision-CPU) close to the computer. Please mind
the maximum cable length of five metres between the computer module and the
computer to be connected.
4. Place the user module (DVIVision-CON) close to the remote console. Please also
mind the maximum cable length of five metres between the user module and the
devices of the user console.
5. Take the included cables and place them ready for the installation of the devices.
Installing the computer module
The computer, whose signals are transmitted to the remote console, is connected to
the DVIVision-CPU computer module. A local console can optionally be connected
to the computer module.
ADVICE: It is recommended to connect the cables block by block and from bottom
to top. This way, already connected cables do not block the interface designations.
