Installation
G&D DVIVision-USB 2.0 · 10
Additional interfaces of multi-channel variants
Transmission x:
Insert the twisted pair cable, which is connected to the Transmission x
interface of the computer module.
DVI/VGA Out x:
Connect the monitor of the local console to this interface.
If the monitor only provides an analog VGA input, connect an optional adapter to
this interface. Afterwards, connect the monitor’s VGA cable to the adapter.
NOTE:
The computer module provides additional Transmission x, DVI/VGA Out x
und DVI CPU x interfaces for each additional video channel.
The names of the interfaces show the channel number.
