Installation
7 · G&D DVIVision-USB 2.0
Additional interfaces of multi-channel variants
Transmission x: Connect the category 5e (or better) twisted pair cable, which is availa-
ble as accessory, to this interface. Connect the other end of the cable to the respec-
tive interface of the user module.
DVI/VGA Out x: Connect the monitor of the local console to this interface.
If the monitor only provides an analog VGA input, connect an optional adapter to
this interface. Afterwards, connect the monitor’s VGA cable to the adapter.
DVI CPU x: Use the DVI-D-SL-M/M-2 cable to connect the digital video output of the
computer to this interface.
NOTE: The computer module provides additional Transmission x, DVI/VGA Out x
und DVI CPU x interfaces for each additional video channel.
The names of the interfaces show the channel number.
