Installation Guide
17 · G&D CATCenter NEO4
Activating and operating the user module OSD
Calling the OSD requires the first or the second channel to be switched to the user
module UCON-s resp. UCON-Audio-s. Proceed as described above in order to switch
one of these two channels.
How to activate the OSD of the user module:
 Press the hotkey that has been defined in the CATCenter system (default: Ctrl) and
the NUM key.
Use the arrow keys Up and Down or the mouse wheel to navigate through the menu
items.
The following chapter describe how to operate the single entries.
Changing the preset selectkeys
Hint: Any changes in the standard configuration of the user module UCON-s do
only apply for the configured device. These settings are independent from the
system settings at the CATCenter system. The following steps therefore have to
be carried out at each connected user module.
How to change the preset selectkey:
 Activate the OSD as described above and mark the row Select Key.
 Press F8 to select between the following options:
1 - 3: keys 1, 2, and 3 at the alphanumeric keypad
NUM1 - NUM3: keys 1, 2, and 3 at the numeric keypad
A-C: keys a, b, c
F1 - F3: function keys F1, F2, F3
