Installation Guide
G&D CATCenter NEO4 · 30
User module UCON
Signal type:
analog video
Graphics
video resolution:
(local connection)
max. 1920 × 1440 @ 75 Hz
(depending on cable length)
Distance between user module
and target module:
max. 300 m
Transmission type to user
module:
dedicated CAT-x connection
Transmission
Delay compensation:
yes
Number:
1
User consoles
Additionally connectable
console computer:
0
Type:
internal power pack
Connection:
IEC plug (IEC-320 C14)
Main power
supply
Voltage: AC100-240V/60-50Hz
Type:
external power pack
Connection:
miniDIN-4 power socket
Redundant
power supply
Voltage:
+12VDC
Material: anodised
aluminium
Dimensions (W × H × D):
desktop: 270 × 44 × 211 mm
rackmount: 19” × 1HU × 211 mm
Casing
Weight:
approx. 1,3 kg
Temperature:
+5 to +45 °C
Operational
environment
Air humidity:
< 80%, non-condensing
Interfaces
for user module:
1 × D-Sub HD 15 socket (video)
2 × PS/2 socket (keyboard/mouse)
2 × USB-A socket (keyboard/mouse)
1 × D-Sub 9 socket (LED)
to matrix switch:
1 × RJ45 socket
for update:
1 × 2,5 mm jack plug
Conformity
CE, RoHs
