SERVICEANLEITUNG TNC 306/360
Blatt 42
HEIDENHAIN Kundendienst
9.2.5 Tasten-Matrix
X2 Pin 1 2 3 4 5 6 7 8 20 21 22 23 24 25 26 27
Taste RL0 RL1 RL2 RL3 RL4 RL5 RL6 RL7 SL0 SL1 SL2 SL3 SL4 SL5 SL6 SL7
PGM
NR
⊕ ⊕
CL
PGM
⊕ ⊕
PGM
CALL
⊕ ⊕
CR
L
⊕ ⊕
RND
⊕ ⊕
CT
⊕ ⊕
CC
⊕ ⊕
C
⊕ ⊕
MOD
⊕ ⊕
BLK
FORM
⊕ ⊕
MAGN
⊕ ⊕
START
⊕ ⊕
