17 GB/IE
Use
longer trips, partial unloading must be considered. Calculate the number of
lashing devices according to EN 12195-1. Only lashing systems labelled
for lashing down with STF (standard tension force) may be used for friction
lashing.

Place the lashing strap around the load.

Open the ratchet handle 1 and place the slotted shaft 3 into the
position so that the webbing 4 can be inserted into it (see Fig. A III).

Insert the webbing 4 into the slotted shaft 3 of the ratchet. Carefully
pull it through the slotted shaft 3 until the webbing 4 lies snug
against the load.

Tighten the lashing strap by moving the handle 1 of the ratchet
backwards and forwards (see Fig. A I - III). Tighten the lashing strap
until you have obtained the tension you wish to have.
Note: Make sure that webbing 4 is wound at least 1.5 times to a
maximum of 3 times around the slotted shaft 3 .

Bring the ratchet handle 1 into the basic position (see Fig. A I). The
load is now secure.
