CIRCUTOR CVM-C10 Series - Handbuch (Seite 76)

DESCRIPTION SYMBOL ID OBJECTS OBJECT NAME UNITS
Wirkleistung Active power kW 2 AI7 ActPwrPh2 kW
Blindenergie Reactive power kvar 2 AI8 ReactPwrPh2 kvar
Leistungsfaktor Power factor PF 2 AI9 PwrFactPh2 PF
Spannung Phase-Neu-
tralleiter
Voltage phase to
neutral
V 3 AI10 Ph2NU3 V
Stromstärke Current A 3 AI11 Ph3Current A
Wirkleistung Active power kW 3 AI12 ActPwrPh3 kW
Blindenergie Reactive power kvar 3 AI13 ReactPwrPh3 kvar
Leistungsfaktor Power factor PF 3 AI14 PwrFactPh3 PF
Dreiphasige Wirkleis-
tung
Three phase active
power
kW III AI15 ActPwOn3Ph kW
Dreiphasige induktive
Blindenergie
Three phase reactive
inductive power
kvarL III AI16 InductPwOn3Ph kvarL
Dreiphasige kapazitative
Blindenergie
Three phase capacitive
inductive power
kvarC III AI17 CapPwOn3Ph kvarC
Cos φ dreiphasig Three phase cos φ Cos φ III AI18 Cosphi Cos φ
Dreiphasiger Leistungs-
faktor
Three phase power
factor
PFIII AI19 PwFactOn3Ph PF
Frequenz (L2) Frequency Hz AI20 Frequency Hz
Spannung Phase-Phase Voltage phase to phase V12 AI21 Ph2PhU12 V
Spannung Phase-Phase Voltage phase to phase V23 AI22 Ph2PhU23 V
Spannung Phase-Phase Voltage phase to phase V31 AI23 Ph2PhU31 V
% THD V %THD V %THD V1 AI24 THDVal_U1 %THD
% THD V %THD V %THD V2 AI25 THDVal_U2 %THD
% THD V %THD V %THD V3 AI26 THDVal_U3 %THD
% THD A %THD A %THD A1 AI27 THDVal_I1 %THD
% THD A %THD A %THD A2 AI28 THDVal_I2 %THD
% THD A %THD A %THD A3 AI29 THDVal_I3 %THD
Wirkleistung Active energy kW•h III AI30 ActEnergy kW•h
Induktive Blindenergie
Reactive inductive
energy
kvarL•h III AI31 InductEnergy kvarL•h
Kapazitative Blindener-
gie
Reactive capacitive
energy
kvarC•h III AI32 CapEnergy kvarC•h
Dreiphasige Scheine-
nergie
Three phase aparent
energy
kVA•h III AI33 AppEnergy kVA•h
Erzeugte Wirkenergie
Three phase generated
active energy
kW•h III (-) AI34 ActEnergy_exp kW•h
Erzeugte induktive
Energie
Three phase genera-
ted reactive inductive
energy
kvarL•h III (-) AI35 IndEnergy_exp kvarL•h
Erzeugte kapazitative
Energie
Three phase genera-
ted reactive capacitive
energy
kvarC•h III(-) AI36 CapEnergy_exp kvarC•h
Erzeugte Scheinenergie Three phase generated
aparent energy
kVA•h III (-) AI37 AppEnergy_exp kVA•h
Dreiphasiger Strom
(Mittelwert)
Three phase average
current
I_AVG AI38 AvgValCurr3Ph I_AVG
Neutralleiterstrom Neutral current In AI39 NeutralCurrent In
Scheinleistung L1 Aparent power L1 kVA AI40 AppPwrPh1 kVA
Scheinleistung L2 Aparent power L2 kVA AI41 AppPwrPh2 kVA
76
