DESCRIPTION
SYMBOL
ID OBJECTS OBJECT NAME
UNITS
Scheinleistung L3
Aparent power L3
kVA
AI42
AppPwrPh3
kVA
Dreiphasige Scheinleis-
tung
Three phase aparent
power
kVAIII
AI43
AppPw3Ph
kVA
Spitzenbedarf I1
Maximum demand I1
Md (A1)
AI44
MaxDemand_A1
A
Spitzenbedarf I2
Maximum demand I2
Md(A2)
AI45
MaxDemand_A2
A
Spitzenbedarf I3
Maximum demand I3
Md(A3)
AI46
MaxDemand_A3
A
Spitzenbedarf A
Maximum demand A
A III
AI47
MaxDemand_A
A
Spitzenbedarf kW
Maximum demand kW
kW III
AI48
MaxDemand_kW
kW
Spitzenbedarf kVA
Maximum demand kVA
kVA III
AI49
MaxDemand_
kVA
kVA
Analog Value Object Type
1. Dynamically creatable using BACnet’s CreateObject service?
No
2. Dynamically deleatable using BACnet’s DeleteObject service?
No
3. List of optional properties supported:
4. List of all properties that are writable where not otherwise required by this standard
5. List of propietary properties:
Property Identifier
Property Datatype
Meaning
5. List of object identifiers and their meaning in this device
Object ID
Object Name
Description
AV1
MAC_Address
MAC
AV2
BaudRate
BAUD RATE
AV3
Device_ID
DEVICE ID
Device Object Type
1. Dynamically creatable using BACnet’s CreateObject service? No
2. Dynamically deleatable using BACnet’s DeleteObject service? No
3. List of optional properties supported:
Description, Protocolo_Conformance_Class
4. List of all properties that are writable where not otherwise required by this standard
Object_Name
Max_Master
Max_Info_Frames
Object_Identifier
5. List of propietary properties:
5. List of any property value range restrictions
Property Identifier
Restrictions
Object_Name
< 7 bytes
Object_Identifier
Device Type only
Number_Of_APDU_Retries
0-255
APDU_Timeout
0-65535 miliseconds
Vendor_Identifier
0-65535
Data Link Layer Options (check all that supported):
X
MS/TP master (Clause 9), baud rate(s): 9.6, 19.2kB/s
Character Sets Supported (check all that apply):
Indicating support for multiple character set does not imply that they can all be supported simulta-
neously.
X
ANSI X3.4
