The KVM switch »DL-MUX«
2 · G&D DL-MUX4
The KVM switch »DL-MUX«
The KVM switch DL-MUX4 enables the user to operate up to four computers through
one console.
A computer, which is connected to the KVM switch, can be accessed
 by pressing either the buttons at the device,
 via configured select keys,
 via configured step keys,
 via a serial interface,
 via Config Panel web application
 or via SNMP.
The front panel of the device provides two USB 2.0 interfaces to operate any USB
devices. The connected USB devices are supplied to the active computer.
The KVM switch operates with full keyboard and mouse emulation on each chan-
nel and therefore guarantees error-free booting and secure operation at all connected
computers.
Scope of delivery
 1 × KVM switch DL-MUX4 (basic or multichannel variant)
 1 × 19" RM-Set-435
 1 × Service cable (USB-Service-2)
 2 × IEC cable (PowerCable-2 Standard)
 1 × Installation and Operating Guide
 1 × Operating Guide Config Panel web application
NOTE: If the computers to be operated are provided with several video outputs, a
multi-channel variant can be used to output each video signal separately on a con-
sole monitor.
NOTE: KVM cable sets are used to connect the computers to the KVM switch.
PS/2 as well as the USB variants of these cable sets are available in different
lengths.
