Initial configuration of the network settings
12 · G&D DL-MUX4
8. Use th Interface A and/or Interface Be paragraphs to enter the following data:
9. Enter the following data in the section Global network settings :
10.Click OK to save your data.
11.Click the Logout symbol (see figure on the right) to end the current session
of the web application.
12.Remove the twisted pair cable between the computer and the computer or the
KVM switch.
13.Integrate the KVM switch into the local network.
Operational mode: Use the pull-down menu to select the operational mode of
Interface A or Interface B :
 Off: switch network interface off.
 Static: a static IP address is being assigned.
 DHCP: obtains the IP address from a DHCP server.
IP address: Only when the Static operating mode has been selected:
Enter the interface IP address.
Netmask: Only when the Static operating mode has been selected:
Enter the network netmask.
Connection type: Select when the network interface and its communication
partner are to negotiate the connection type automatically
( Auto ) or select one of the available types.
Operational mode: Select the desired operational mode:
 Static: use static settings.
 DHCP: obtain the settings from a DHCP server.
Hostname: Enter the hostname of the device.
Domain: Enter the domain to which the device is to be assigned to.
Gateway: Enter the gateway IP address.
DNS-Server 1: Enter the DNS server IP address.
DNS-Server 2: Optionally, enter the IP address of another DNS server.
