Configuration
G&D DL-MUX4 · 25
English
How to change the settings of the scancode set:
(De)activating the switching
A computer, which is connected to the KVM switch, can be accessed by pressing
either the buttons at the device or configured hotkeys (select or step keys). It can also be
accessed via a serial interface.
After you purchased and activated the DevCon function, you can use the Config Panel
web application or SNMP to switch to the IP protocol.
If desired, the switching possibilities can be limited.
Setup
mode
1. Press Hotkey+Backspace (default: Ctrl + Backspace ) to activate the setup mode.
If the hotkey delay is activated, press the key combination during the adjusted time
(default: 7 seconds).
2. Press one of the setup keys listed below to activate a particular scancode set:
2  activate scancode set 2 for PS/2 keyboard inputs
3  activate scancode set 3 for PS/2 keyboard inputs
3. Restart the KVM switch.
After the restart, the keyboard is being initialised and the selected scancode set is applied.
Config
Pan
el 1. Use the tree view to click on KVM switches > [All switches] .
2. Right-click the KVM switch and click on the Configuration entry in the con-
text menu.
3. Click the General tab.
4. Use the field Scancode Set to select between the following options:
Set 2  activate scancode set 2 for PS/2 keyboard inputs
Set 3  activate scancode set 3 for PS/2 keyboard inputs
5. Click OK to save your changes.
6. Restart the KVM switch.
After the restart, the keyboard is initialised and the selected scancode set does apply.
