Configuration
16 · G&D DL-MUX4
The following pages provide a detailed description of how to operate the setup
mode (see page 16) and the Config Panel web application (see page 17).
Operating the setup mode
The configuration of the KVM switch can either be changed in the setup mode or in
the Config Panel web application.
The setup mode can be enabled using the console keyboard. After enabling, the con-
figuration of the KVM switch can be changed by using various step keys.
How to activate the setup mode:
 Press the Hotkey+Backspace (default: Ctrl+Backspace ) key combination to enable
the setup mode.
How to perform a setup function:
 After enabling the setup mode, press one of the setup keys described on the fol-
lowing pages.
How to end the setup mode without performing a function:
 Press ESC to end the setup mode.
NOTE: The descriptions of the configurable functions on page 18 include informa-
tion on how to carry out the configuration via the setup mode and the Config Panel
web application.
NOTE: Only one setup function can be performed after the calling of the setup mode.
If you want to perform more functions, please restart the setup mode.
IMPORTANT: The key combination for enabling the setup mode needs to be
pressed for seven seconds.
After the first call of the setup mode, the hotkey delay can be disabled by press-
ing the setup key 8 (see page 18).
NOTE: The successful activation of the setup mode is displayed by the blinking
NUM ,  and Scroll control LEDs on the keyboard
The Caps Lock, NUM and Scroll LEDs are blinking alternately at the other con-
sole.
