Configuration
16 · G&D TradeSwitch8-USB
The setup menu lists all settings in tabular form:
The right column displays the active setting of the respective function.
Menu items with submenus containing more settings are indicated with three dots
(...) in the right column.
How to operate the setup menu:
1. Use the
Arrow
or
Arrow
keys to select the desired menu item.
The active row is marked with angular arrows .
2. Depending on the type of menu item, the following action(s) can be carried out:
Menu items whose settings are displayed in the right column can be changed
by pressing the
Space
key (repeatedly).
A menu item that has a sub-dialogue available can be opened by pressing
Enter
.
Settings for TradeSwitch8
Show System Info
...
Hotkey:
Alt Gr
Double Hotkey:
NO
Select Key:
1..8
Hotkey Delay: Yes
Set System Defaults
...
Select Ch.1 after Power up:
No
Select Channel via Front Button:
Yes
Select Channel via Hotkey:
Yes
Select Channel via Step Key:
No
Select Channel via Mouse:
No
CrossDisplay Switching:
No
CrossDisplay Switching Mouse Speed:
5
Service RS232 Bitrate:
115200
Service RS232 Startup Mode: Setup Menu
PS/2 Scancode Set:
2
PS/2 Keyboard Type:
Standard
USB Keymode:
...
USB2.0 Function:
enabled
USB Pinning:
disabled
'Space': Toggle 'S': Save
NOTE:
The
PS/2 Scancode Set
and
PS/2 Keyboard Type
are only relevant PS/2 variants
of the KVM switch and are therefore not described in this manual.
NOTE:
The following pages provide detailed information on how to change a cer-
tain function.
