Hypertherm MAXPRO200 Rev.1 - Handbuch (Seite 201)

199
Power Supply
Shield Plasma
Air 02
4'
21', 46', 71', 96'
Torch Valve
P1 P2
B2 B1
I/O board
Black Hose
Plasma Gas Shield Gas & Pilot Arc
Blue Hose
Power Supply
Shield Plasma
N2
4'
21', 46', 71', 96'
Torch Valve
P1 P2
B2 B1
I/O board
Black Hose
Plasma Gas Shield Gas & Pilot Arc
Blue Hose
Power Supply
Shield Plasma
Air
Air/Air
4'
21', 46', 71', 96'
Torch Valve
P1 P2
B2 B1
I/O board
Black Hose
Plasma Gas Shield Gas & Pilot Arc
Blue Hose
N2/N2
O2/AIR
Plugged
Hand/Mech
Torch Hand/Mech
Torch Hand/Mech
Torch
Filter
Regulator
Pressure gage Filter
Regulator
Pressure gage Filter
Regulator
Pressure gage
MAXPRO 200
Gas Schematic
