23
Varyscan
®
4 1200 HMI
R30 2R 1W
R31 750R 0,6W
R32 250R 0,6W
R33 1,2R 1W
R34 1,2R 1W
R35 1,5R 1W
R36 1,5R 1W
R37 1,2R 1W
R38 1,2R 1W
R39 1,2R 1W
R40 1,2R 1W
C1 18pF C41 220nF
C2 18pF C42 2,2nF
C3 4,7uF C43 220uF
C4 100nF C44 220nF
C5 100nF C45 2,2nF
C6 100nF C46 100nF
C7 22uF C47 470uF
C8 100n C48 100nF
C9 100nF C49 47uF
C10 820pF C50 220nF
C11 820pF C51 47uF
C12 47uF C52 220nF
C13 220nF C53 47uF
C14 220nF C54 220nF
C15 47uF C55 4700uF
C16 220nF C56 4700uF
C17 220nF C57 4700uF
C18 100nF C58 47uF
C19 3,3nF C59 220nF
C20 220nF C60 2,2nf
C21 47uF C61 47uF
C22 220nF C62 220nF
C23 47uF C63 47uF
C24 820pF C64 220nF
C25 820pF C65 47uF
C26 3,3nF C66 220nF
C27 nb C67 2,2nF
C28 220nF C68 100nF
C29 2,2nF C69 4,7uF
C30 47uF C70 100nF
C31 220nF
C32 47uF
C33 220nF
C34 nb
C35 220nF
C36 2,2nF
C37 nb
C38 220nF
C39 2,2nF
C40 nb
